IMS II - 17230 - Universal cable stripper for primary conductor-insulation

APPLICATION RANGE: Ø 15 - 52 mm

INSULATION THICKNESS: 0 - 15 mm

SUGGESTED APPLICATION: Any type of primary insulation

Technical characteristics:

• Designed for stripping the primary insulation of medium-voltage cables from 6 to 45 kV
• Lightweight, robust design thanks to the use of light metals and anodized surface
• Helical and circular cuts
• Cutting depth adjustable from 0 to 15 mm
• Max. rotating diameter 220 mm
• Snap knob to activate/deactivate axial feed
• Feed rate selectable in 5 steps
• Optimal sliding properties due to the coated contact surface
• Positioned on the cable like a vice system
• Designed to strip both ends
• Unlimited stripping length; the stripping process can be stopped at any point on the cable
• Interchangeable blade

Spare blade: 17232

Spare parts kit (2x plates, 1x roll, suitable screws): 17235

Set equipment:

IMS II - cable stripper 17231

2,5 mm Allen wrench 17100

Tube of silicone grease AG1013

Rigid resin case AB17230

280 x 210 x 65 mm

1 kg

Attention: Not suitable for work under voltage!
